ID: 410 Open
TALADRO MULTIPLE DOBLE

TALADRO MULTIPLE DOBLE

AMXmachinery

Contact Seller
Description

PARTE: 2LO-BR-2142B - TALADRO MULTIPLE DOBLE

The machine is standard designed and constructed for Horizontal and Vertical boring units.

Each 21 horrizontal and 42 vertical drills, drill head can be adjust to any degree position for X or Y axis combination construction drill.

The machine is easy to operate. Simply press the foot switch and entire horizontal and vertical boring operations can be accomplished quickly.

Vertical boring for drilling at longitudinal and cross direction

The vertical boring units can be adjusted up & down and right & left. Readouts are provided for accurate indication of adjustment.

The end horizontal-boring unit can be adjusted up & down, in & out stroke.

An emergency switch is provided on the top beam, allowing the operator to stop the machine conveniently.

The panel clamp is adjustable at any position.

Square slide way for vertical boring unit, providing maximum rigidity and stability for boning operations.

Specifications

M-LB-BR-2142B

Max. Distance Between Centers

1¼" (32 mm)

Number of Spindle Per Boring Head

21(Horizontal) 21 x 2 (Vertical)

Max. Boring Depth

3" (80 mm)

Total Motor Power

2 HP x 3

Spindle Speed

2800 RPM

Max. Distance Vertical Head

43½" (1100 mm)

N. W.

1367 LBS (620 kg)

G. W.

1610 LBS (730 kg)

Machine Size

79" x 50" x 51"

(2000 x 1260 x 1300 mm)

Packing Size

88" x 52" x 62"

(2235 x 1320 x 1575 mm)

Payments & Returns
Payment Methods
Visa/Mastercard/American Express, Transferencia/Deposito Bancario
Post Message
Sign in to ask the seller a question.
CABEZALES PARA TALADROS - DISTANCIA AJUSTABLE
AMXmachinery
CABEZALES PARA TALADROS - DISTANCIA AJUSTABLE
PARTE: 2LO-A-2CWSERIES - CABEZAL PARA TALADROS - DISTANCIA AJUSTABLEMicro Adjustable.Maximum flexibility of drills distance application.Accurate center distance positioning.Heavy-duty construction requires minimum maintenance.Fast setup that helps reduce boring downtime. SpecificationsDimensionsABCDEFA-2CW130.39" (10 mm)0.39" (10 mm)1." (28 mm)2" (55 mm)4" (106.5 mm)2" (57 mm)A-2CW185" (127.5 mm)3" (67 mm)A-2CW195" (127.5 mm)3" (67 mm)A-2CW226" (143 mm)3" (82 mm)A-2CW258" (191 mm)4" (109 mm)...
SIERRA TRONZADORA 18" DERECHA / IZQUIERDA
AMXmachinery
SIERRA TRONZADORA 18" DERECHA / IZQUIERDA
PARTE: 2EX-XC-18L – SIERRA TRONZADORA – DISCO 18” – MOTOR 10 HP – IZQUIERDA – LEFTPARTE: 2EX-XC-18R – SIERRA TRONZADORA – DISCO 18” – MOTOR 10 HP – DERECHA – RIGHT - OPCIONALNUEVA CON GARANTIAMAQUINA DISPONIBLE PARA USO DERECHO O PARA USO IZQUIERDOPARA DISCO DE CORTE 18"MOTOR 10 HP, 220/460V, 3 FASESFLECHA DE 1" DIAMETROCUBIERTA DE USO RUDO DE FIERRO FUNDIDOCONSTRUCCION DE ACERO PESADO PARA EVITAR VIBRACIONESMAQUINA PARA USO RUDO INDUSTRIALVIAJE DE LA SIERRA CON VELOCIDAD...
HORNO DE AIRE CALIENTE - WELDTRON – 6028
AMXmachinery
HORNO DE AIRE CALIENTE - WELDTRON – 6028
PARTE: AMX-10042 - HORNO DE AIRE CALIENTE - WELDTRON – 6028EN BUENAS CONDICIONES DE OPERACIONMODEL # 6028VOLTS: 230CYCLE: 60PHASE: 3AMPS: 44FWO: 31627WATTS: 15FABRICANTE: WELDTRON CORPORATION, NEW JERSEY, USADIMENSIONES MAQUINA:76" LARGO X 34" ANCHO X 63" ALTOPESO ESTIMADO: 300 KGSVIDEO DE LA MAQUINA FUNCIONANDO:     VIDEO 1
EXTRACTOR DE PARED - 17” X 17” - S & P
AMXmachinery
EXTRACTOR DE PARED - 17” X 17” - S & P
PARTE: AMX-10166 - EXTRACTOR DE PARED - 17” X 17” - S & P USADO MUY BUENAS CONDICIONES MODELO: HXB-4-400/20 3,600 M3/HR MOTOR: ¼ HP, 127V, 1 FASE, 2.2 AMP RPM: 1625 MEDIDAS: 20” X 20” X 10”
